DM 2000

3 Adjustments Manual Bed

The TRINODAL DM2000 Manual Fowler Bed is developed for hospitals, clinics and healthcare facilities requiring durable, practical and cost-effective patient care solutions.

The bed features manual backrest and kneerest adjustment functions designed to support patient comfort during examination, treatment, recovery and hospitalization.

Manufactured with an epoxy powder coated steel frame, aluminum top foldable side rails and HDPP head & foot boards, the DM2000 provides durability, patient safety and easy cleaning for intensive daily healthcare use.

The bed is equipped with a 4-section mattress platform, ergonomic manual crank systems and Ø125 mm cross lockable castors for practical operation and stable patient positioning. Optional accessories including ABS mattress platform, IV pole, trapeze bar and urine bag holders allow flexible configuration according to different healthcare requirements.

  • 2 Adjustment Manual Bed
  • 70° Backrest Adjustment
  • 45° Kneerest Adjustment
  • 4 Section Metal Mattress Platform
  • Aluminum Top Foldable Side Rails
  • HDPP Head & Foot Boards
  • Epoxy Powder Coated Main Frame
  • Four Corner Bumpers
  • Cross Lockable Castors (125Ø mm)
  • Bed Surface: 900 x 1900 mm
  • Height (Up to Mattress Platform): Fixed Height
  • External Dimension: 1050 x 2145 mm
  • Standard Weight Capacity: 210 kg
  • Cross Lockable Castors: Ø125 mm
  • ABS Mattress Platform
  • Painted IV Pole
  • Stainless Steel IV Pole
  • Trapeze Bar for Patient Lift
  • Semi-Automatic Rack System Foot Section Adjustment
  • Urine Bag Holder
